General
Device Type
Switch - 48 Ports - L3 - Managed
Services in Bundle
1 Year Premium Support with Hardware Warranty Next Business Day
Chassis Type
Front-to-back Airflow Rack-mountable 1U
Subtype
10 Gigabit Ethernet
Ports
48 x 10 Gigabit SFP+ + 4 x 100 Gigabit QSFP28 + 2 x 40 Gigabit QSFP+
Performance
Switching Capacity: 1.76 Tbit/s
Throughput: 1320 Mpps
Capacity
MAC Address: 160000
ARP Entries: 128000
IPv4 Routes: 128000
IPv6 Routes: 64000
IPv6 Hosts: 64000
Multicast Hosts: 8000
Links per Group: 16
Link Aggregation Groups: 128
Layer-2 VLANs: 4000
MSTP Instance: 64
MAC Address Table Size
160,000 Entries
Routing Protocol
OSPF, BGP-4, OSPFv2, Policy-Based Routing (PBR)
Remote Management Protocol
SNMP 1, SNMP 2
Authentication Method
RADIUS, TACACS
Performance Features
Flow Control, ARP Support, Port Mirroring, STP Support, RSTP Support, VRRP Support, MSTP Support, ACL Support, QoS, LACP Support, LLDP Support, GVRP, PFC, ICMP, DNS Client
Product Certifications
IEEE 802.3u, IEEE 802.3i, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.3ac, IEEE 802.1s, IEEE 802.1t, IEEE 802.1ab (LLDP), IEEE 802.3ba, IEEE 802.1Qbb, IEEE 802.1Qaz, IEEE 802.3bj
Expansion/Connectivity
Interfaces
48 x 10Gbit-LAN SFP+
2 x 40Gbit-LAN QSFP+
4 x 100Gbit LAN QSFP28
1 x Serial (RS-232) RJ-45 Management
Power Supply
Power Supply Unit
External Power Adapter - Hot-Plug
Redundant Power Supply
Yes
Required Line Voltage
AC 120/230 V (50/60 Hz)
Operating Power Consumption
370 Watt
Miscellaneous
Product Certifications
EN 61000-3-2, EN 61000-3-3, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-6, EN 61000-4-5, RoHS, UL 60950-1 Second Edition, EN 60825-1, EN 60825-2, EN 60950-1 Second Edition, IEC 60950-1 Second Edition, ICES-003 issue 4 Class A, EN 300 386 V1.4.1, FDA 21CFR1040.10, FDA 21CFR1040.11, AS/NZS CISPR 32 Class A, VCCI V-3/2009 Class A, CSA 60950-1 Second Edition, EN 55032:2015+A1:2007, FCC CFR47 Part 15 B 2009 Class A, EN 55024:1998+A1:2001+A2:2003
Dimensions and Weight
Environmental Conditions
Min Operating Temperature
0 °C
Max Operating Temperature
40 °C
Allowable Operating Humidity
10 – 85% (Non-condensing)
Min Storage Temperature
-40 °C
Max Storage Temperature
70 °C
Allowable Storage Humidity
5 - 95 % (Non-condensing)
