General
Device Type
Power supply - internal
Specification Compliance
ATX12V / SFX12V
Image Colour Disclaimer
The displayed product image may be a different colour
Power Device
Input Voltage
AC 100-240 V
Frequency Required
50 - 60 Hz
Power Output Connectors Details
1 x power 24 pin ATX with detachable 4 pin section ¦ 1 x power 8 pin +12V with detachable 4 pin section ¦ 4 x 8 pin PCI Express power with detachable 2 pin section ¦ 6 x 15 pin Serial ATA power ¦ 3 x 4 PIN internal power
Output Voltage
DC +3.3, DC +5, DC ±12 V
Output Current
+3.3V - 20 A ¦ +5V - 20 A ¦ +12V - 62 A ¦ -12V - 0.3 A ¦ +5VSB - 3 A
Efficiency
92% at 50% Load
Modular Cable Management
Yes
80 PLUS Certification
80 PLUS Platinum
Miscellaneous
Included Accessories
SFX to ATX bracket
Features
On/off switch, overheat protection, gold-plated terminals, over current protection, over voltage protection, overpower protection, undervoltage protection, short-circuit protection, fluid dynamic bearing cooling fan, Premium Hybrid Fan Control, fully modular, Seasonic S3FC fan Control, fanless mode, silent mode, cooling mode
Compliant Standards
TUV, BSMI, CB, CCC, RoHS, WEEE, cTUVus, Energy-Related Products (ErP) Lot 6, REACH, EAC
Environmental Standards
Manufacturer Warranty
Service & Support
Limited warranty - 10 years
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
50 °C
Dimensions & Weight
Product safety information
Manufacturer information:
Sea Sonic Europe B.V.
Rietveld 7
Berlicum, Niederlande,
sales@seasonic.eu
https://seasonic.com/de/
