General
Device Type
Switch - 12 ports - Managed
Enclosure Type
DIN rail mountable, wall-mountable
Ports
8 x 10/100/1000 + 4 x Gigabit SFP
Performance
Switching fabric bandwidth: 24 Gbps ¦ Throughput: 17.85 Mpps
Capacity
Virtual interfaces (VLANs): 4095 ¦ Routing table entries: 32
Routing Protocol
IGMPv2, IGMP, IGMPv3, MLDv2, MLD
Remote Management Protocol
SNMP 1, SNMP 2, RMON, Telnet, SNMP 3, SNMP 2c, HTTP, TFTP, SSH, CLI
Authentication Method
RADIUS, TACACS+
Features
Flow control, routing, DHCP support, auto-negotiation, BOOTP support, VLAN support, Syslog support, port mirroring, store and forward, IPv6 support, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Multiple Spanning Tree Protocol (MSTP) support, DHCP snooping, Access Control List (ACL) support, Quality of Service (QoS), Dynamic ARP Inspection (DAI), IPv4 support, LLDP support, Link Aggregation Control Protocol (LACP), SNMP trap, Class of Service (CoS), Denial of Service (DoS), 6KV ESD Protector, DiffServ Code Point (DSCP) support, Ethernet Ring Protection Switching (ERPS), IP source guard, Internet Control Message Protocol (ICMP)
Compliant Standards
IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ad
Status Indicators
Power, fail, alarm, link/activity
Expansion / Connectivity
Interfaces
8 x 1000Base-T RJ-45 ¦ 4 x 1000Base-X SFP ¦ 1 x serial (console)
Power
Power Device
Internal power supply
Voltage Required
AC 24 V / DC 12 -72 V
Power Consumption Operational
12 Watt
Miscellaneous
Compliant Standards
IEC 60068-2-27, IEC 60068-2-32, IEC 60068-2-6, IP30
Dimensions & Weight
Environmental Parameters
Min Operating Temperature
-40 °C
Max Operating Temperature
75 °C
Humidity Range Operating
5 - 95% (non-condensing)
Min Storage Temperature
-40 °C
Max Storage Temperature
85 °C
Humidity Range Storage
5 - 95% (non-condensing)
Product safety information
Manufacturer information:
PLANET Germany GmbH
Im Teelbruch 110
Baden-Württemberg
Essen, Deutschland, 45219
info@planet-germany.de
https://planet-germany.de/
